15R - CNG 5000 - COMPRESSED NATURAL GAS HOSE

Thermoplastic antistatic hose for CNG refueling applications up to 350 bar (5000 psi).

Technical details

Inner Tube

Coextruded conductive polyamide and polyamide PA12

Reinforcement

One or two braids of aramid fiber plus one braid of synthetic fiber

Cover

Polyurethane - red - pinpricked - white ink jet branding

Applications

Refueling hose for mobile and stationary units used to refill natural gas vehicles (NGV) tanks - CNG Transfer lines

Features

Static charge dissipating thanks to the conductive inner tube - Optimum bonding between tube braids and cover - Non metallic design - Lightweight and flexible - Extra tough cover for abrasion

Description

High pressure hose suitable for CNG refueling applications featuring conductive inner tube to dissipate static electric build up. Extra tough cover for abrasion water and micro biological resistance. Non metallic lightweight design for easy handling and manipulation. Rugged construction to give kink - crush - twist and pull resistance. Twin lines available with vent hose. Other colors available on request.

Temperature Range

-40 °C to 70 °C (-40 °F to 158 °F)

Specifications

Hose meets applicable requirements of ISO 15500-17, SAE J517 100R8

Hoses Certified "Ansi/Csa Ngv 4.2-2014 - Csa 12.52-2014 - Hoses For Natural Gas Dispensing Systems".
