184 - AUTOMOTIVE LPG

Thermoplastic hose for LPG applications up to 30 bar (435 psi)

Technical details

Downloads

Inner Tube

Polyamide PA6

Reinforcement

One braid of synthetic fiber

Cover

Polyurethane - black - pinpricked - white inkjet branding

Applications

Low pressure hose suitable for LPG applications

Features

Polyamide 6 tube construction compatible with LPG. Non metallic design with bonded construction. Ligthweight and flexible. Antiabrasion cover for optimum wear resistance. Pinpricked cover.

Description

Low pressure hose with black antiabrasion cover suitable for LPG applications. Non metallic lightweight design for easy handling and manipulation.

Temperature Range

-40 °C to 100 °C (-40 °F to 212 °F)

Specifications

Hose meets applicable requirements of Regulation ECE/ONU n. 67/01.

Certificaton number E7 67R01 00951.25

Standard Branding

- Part No - AUTOMOTIVE LPG Class 1 - Inch Size - DN Size - WP bar / psi - 67R01 00951.25 - MADE IN ITALY - MM/YY - Batch No
